Classification 1Ø * 3 Ø Specification
Input Voltage range 110V / 208V / 220V / 380V / 440V / 480V / ±15%
Frequency 50 / 60 Hz
Output Voltage 110V / 208V / 220V / 380V / 440V / 480V
Stability ± 2% (including line/load regulation)
Frequency 50 / 60 Hz
Efficiency 95% or greater
Electric
characteristics		 Response rate 0.048 Sec
Waveform distortion 0.3% or lower
Overload resistance 120% 10minutes
Over/Low Voltage
Protection		 ± 10%
Insulation resistance 5Mohms or greater at DC500V mega
Dielectric strength No problem occurs when AC 1500 60Hz is applied for 1 minute
High frequency problem None
Protector over voltage/low voltage/over current/noise (Impulse)
Item 1￠ Enclosure Remark
1.2 3 5 7.5/10 15/20 30 50
Dimension W 260 250 280 420 450 490 580 Customized
D 350 400 500 470 550 630 640
H 195 320 470 720 800 890 1350
Item 3￠ Enclosure Remark
5 7.5 10 15 20 30 40 50 75 100 150 200
Dimension W 450 460 520 540 560 560 580 650 750 850 1000 1400 Customized
D 520 540 580 600 620 620 640 750 900 1000 1200 1500
H 800 800 1000 1000 1200 1300 1350 1800 1900 2000 2100 230
